Metal Halide 8colors DMX Twinkle IP43 waterproof fiber optic illuminator R-150DMX-WP manufacturer from China HALANCE TECHNOLOGY CO.,LTD

Metal Halide 8colors DMX Twinkle IP43 waterproof fiber optic illuminator

Place of Origin:

Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: R-150DMX-WP

Packing: Standard package,as you req...

Shape: Tubular

Base Type: G12

Power: 150w

Rated Avg. Life: 6000hrs

Emitting Color: Changeable

Light Source: HID

LED power: 150W

IP Rating: IP43

Remote controller: available

Production Capacity: 500 piece /pieces per month

Delivery Date: 3-15 working days

Bulb Type: Others

Certification: CE

Color Temperature: 4000k

Brand Name: HALANCE

Lamp Body Material: Stainless Steel

Voltage: Item Type Fiber Optic Light...

Size: L335*W328*H190

Application: Swimming pool,outdoor decor...

LED brand: PHILIPS and OSRAM

IP43 waterproof fiber optic illuminator
*Max aperture: dia 30mm
*Voltage: 240V AC
*Color Temp: 4200K
*Weight: 12.0kg

Metal Halide,DMX,Twinkle,IP43 waterproof fiber optic illuminator

Metal halide waterproof light source is mainly made of stainless steel, and has a waterproof funcation. It is suitable for the use of rainy weather, swimming pool, fountain etc.

A: R-150DMX Light source Technical Date:

Voltage	240VAC
Fuse	5A
Power consumption	200W
Color	white, purple, yellow, blue, green, orange, sky-blue and grass-green
Lamp	CDM-T 150W/942/HQI-T 150/HDL
Color Temp	4200K
Lamp Life	6000hrs(Under normal usage)
Fiber Connector Diameter	30mm Max
Size	L385W290H190mm
Weight	17kg

B. How to install and adjust the lamp

1) How to install the lamp before usage(Only for T-type lamp. If it is R-lamp, no need to do this procedure)

* Unscrew the lamp Fixing Board Protection Plate at the back of the Light SOURCE. Then unscrew the Lamp Fixing Board Screw, pull gently the lamp Fixing Board backward, until the lamp Scoket is fully out of the light Source.

*Push the lamp into the lamp Socket. Please take care not to touch the glass part of the lamp.

*Push the Board into the light SOURCE, then screw tight the lamp Fixing Board Screw.

*Screw tight the lamp Fixing Board Protection Plate.
